| Processor | Intel Celeron 1037U dual core 1.8 GHz
|
| Chipset | Intel HM77
|
| System Memory | 2GB DDR3L 1600 (Expandable, up to 8GB)
|
HDD Slot
| 4 |
SATA DOM
| SATA III 8GB
|
HDD Support
| SATA II / SATA III
|
HDD Type
| - ‧ 3.5" HDD
- ‧ 2.5" HDD / SDD
|
Max HDD Capacity
| 24 TB (6 x 4 TB HDD)
|
RAID Support
| Hardware RAID (0,1,5,10)
|
Hot Plug
|
|
USB 2.0 Port
| front 1 back2
|
USB 3.0 Port
| back 2
|
Audio
| MIC 1 ,Earphone 1
|
Internal HDD
| EXT4
|
External HDD
| - ‧ EXT4
- ‧ EXT3
- ‧ FAT
- ‧ NTFS
- ‧ HFS+ (read-only)
|
Size (w x d x h) mm
| 383 (D)x 430(W) x 43.4(H)mm
|
Weight [kg]
| 4.08
|
NIC Port
| Intel82574 Gigabit Ethernet X 2
|
Wake on LAN
|
|
System Fan
| 2 |
Supports external wireless dongle
|
|
Internal Wifi and BT (optional)
| wireless 802.11ac. Bluetooth 4.0
|
HDMI (1.4a)
|
|
| VGA Port | Reserved for system maintenance
|
| PCIe 16x slot(4x) | 1 |
| Internal Audio | 6 channel ALC 662 chipset
|
| Noise | 35db
|
Power auto ON
|
|
Power Supply
|
|
AC input voltage
| 100V/ 240V
|
Current Frequency
| 50/60Hz
|
Power consumption
| 29W
|
Operation Temp
| 5°C to 35°C (40°F to 95°F)
|
Storage Temp
| -10°C to 70°C (15°F to 155°F)
|
Relative Humidity
| 5% to 95% RH
|
Certified
| |
Warranty
| 2 years |
